Yakakwira kumhanya

Model:KGH15L

Unleash yako yekugadzira simba neKGH Speed Speed 15L Imwe Station Blow Malding Malding Molding Moland yemuchina, iyo inotsanangurira mari yekuwedzera kwePlastic Extrusive Block Molding Molding Machine 5l application! Yakachengetedzwa ruoko chimiro chinyararire mudziyo kupa zvakanyanya kuvharika simba simba, ita bhodhoro rakakwana / barrel chimiro.

Vhoriyamu: 15LKurera: 7.5T

Send Inquiry

Product Description Specification Application

Iyo KGH15L yakakwira kumhanya Kutarisa kukwidziridza kune akangwara kugadzirwa. Yayo Modular Dhizaini Inotsigira Ramangwana rekuwedzera uye kukwidziridzwa, vachiita kuti zvienderane ne automation module senge otomatiki chikamu kubvisa uye online kuongorora, kubatsira mafekitori achifamba vakananga kuindasitiri 4.0.

Zvimiro uye Zvakanakira

Iyo imwe-station inoramba ichivhuvhuta muchina inogadzirwa yakagadzirirwa kugadzirwa kwepamusoro-vhoriyamu yekugadzira, kupa zvese zvinoshanduka uye nekubudirira kwemidziyo kusvika 15l. Dhizaini yaro inobvumira kuti ichinje nyore nyore pakati peimwe uye yakawanda-kufa mumusoro wemusoro, inovimbisa kuita kwakakwana pamatanho akasiyana siyana.
Muchina uyu unomira kunze kwekubudirira kwayo, kuita kuti kushandurwa nekukurumidza pakati pekushandurwa kuti uwedzere kubuda uye kuderedza nguva yekugara. Izvo zvinowanzoitika, zvinokwanisa kuburitsa midziyo yakawanda kubva mumabhodhoro kubva kuShampoo mabhodhoro kuna Jerrycans, zvichiita kuti ive yakakodzera kune dzakasiyana-siyana maindasitiri.
Une hunhu hwepamusoro, hunovimbisa kugadzirwa kusingawirirani nekunyatsoziva, kusangana nemhando yepamusoro. Pamusoro pezvo, dhizaini inodhura-inobudirira inoderedza mari yekushandisa apo kugadzirisa kubereka. Yakavakirwa kuvimbika, muchina uyu unoita zvichiramba zvichiitika nemamiriro ezvinhu akagadzikana, kunyangwe mumamiriro ezvinhu akanyanya-anodiwa.
Simudza kugona kwako kugadzirwa neiyi ine simba uye inoshandurwa blow blow yekuumba muchina unoburitsa zvese zvakanaka uye kushanda zvakanaka.

Specifications

Serial number	Material PE、PP、PVC、PA...	Mold-moving series
Serial number	Material PE、PP、PVC、PA...	Machine model:KGH15L
Specifications
1	Max container capacity	15 L
2	Output(dry Cycle)	450 PC/HR
3	Machine Dimension(L×W×H)	4.5 M x 2.2 M x 2.8 M
4	Machine weight	7.5 T
Clamping Unit
1	Clamping force	165 KN
2	Mold platen size(W×H)	500 MM x 550 MM
3	Platen openingstroke	280 MM -680 MM
4	Platen moving stroke	600 MM
5	Max mold size(W×H)	580 MM x 500 MM
6	Mold thickness	300 MM - 380 MM
Power
1	Servooil pump motor power	18.5 KW
2	Servo pump displacement	130 L/MIN
3	Blowpressure	0.6 Mpa
4	Air consumption	0.8 M³/MIN
5	Cooling water pressure	0.2 Mpa - 0.3 Mpa
6	Water consumption	70 L/min
7	Average energy consumption	25-34 KW
Extruder unit
1	Screw diameter	75 MM
2	Screw L/D ratio	25 L/D
3	Melting capacit for HDPE	100 Kg/hr
4	Number of heating zone	4 ZONE
5	Screw heating power	16 KW
6	Screw fanpower	0.6 KW
7	Extruder motor power	30 KW
Die head
1	Number of heating sections	3 * 8 ZONE
2	Heating power	6.5 KW
3	Maxdie-pin diameter	220 MM
4	Accumulator capacity	240 MM - 280 MM
5	(PE)Accumulator weight	150 MM
