15L imwe station blow block Molding Mess

Model:KGB15L

Yakagadzirirwa kugadzirwa kwepamusoro-vhoriyamu, iyi imwe chete-station inoenderera ichirovera muchina wekuumbwa unopfuura kubuditsa mumidziyo kusvika 15l. Dhizaini yayo inochinja-chinja inobvumidza kusanzwisisika kusimuka pakati peimwe uye yakawanda-kufa mumusoro wemusoro, inovimbisa kushanda kwayo kune akasiyana emidziyo. Iwe unogona kutenga 15L imwe station inovhuvhuta muchina kubva fekitori yedu.

Vhoriyamu: 15LKurera: 7.5T

Send Inquiry

Product Description Specification Application

Kubva kuShampoo Mabhodhoro kuna Jerrycan Bottle Blow Broad Machine Symbolitions, iyi 15l Imwe Station Blow Buling Machine inoumbwa inosvina mhando yepamusoro uye inowirirana kuita. Simudza kugona kwako kugadzira nemuchina uyu une simba uye unoverengeka.

Zvimiro uye Zvakanakira

Musoro wemuchina unotora nzira yekudyisa yakagadzirirwa zvakananga
Kuvimba neyakafambira mberi kwemagetsi masisitimu, sekunge tailor Vashandisi vanogona kuita chaizvo calecise maererano nemamiriro ezvinhu chaiwo ekushanda, anoona kuti kugadzirwa uku kunozivisa zvizere zvinodiwa zvemusika. Zvinogona kuita zvekugadzira midziyo 15l nemidziyo yakasiyana senge single-layer inoda kutaridzika kwezvigadzirwa zvemakemikari, chikafu uye chinwiwa, zuva nezuva kuchenesa zvigadzirwa uye mamwe minda.

Specifications

serial number	Material PE、PP、ABS ...	Mold closing oil cylinder(single cylinder)
serial number	Material PE、PP、ABS ...	Machine model:KGB15L
Specification
1	Max container capacity	15L
2	Output(dry Cycle)	450 PC/HR
3	Machine Dimension(L×W×H)	4.5M x2.2 M x2.8 M
4	Machine weight	7.5 T
Clamping Unit
1	Clamping force	165 KN
2	Mold platen size(W×H)	500 MM x 550 MM
3	Platen openingstroke	280 MM - 680 MM
4	Platen moving stroke	600 MM
5	Max mold size(W×H)	580 MM×500 MM
6	Mold thickness	300 MM - 380 MM
Power
1	Servooil pump motor power	18.5KW
2	Servo pump displacement	130 L/MIN
3	Blowpressure	0.6 Mpa
4	Air consumption	0.8 M²/MIN
5	Cooling water pressure	0.2-0.3 Mpa
6	Water consumption	70 L/min
7	Average energy consumption	25 KW-34 KW
Extruder unit
1	Screw diameter	75 MM
2	Screw L/D ratio	25 L/D
3	Melting capacit for HDPE	100 Kg/hr
4	Number of heating zone	4 ZONE
5	Screw heating power	16 KW
6	Screw fanpower	0.6 KW
7	Extruder motor power	30 KW
Die head
1	Number of heating sections	3*8 ZONE
2	Heating power	6.5 KW
3	Maxdie-pin diameter	220 MM
4	2Center distance of double die head	240-280MM
5	2MTMax die-pindiameter	150MM
