30l jerry inogona kuroora kuroora kwechiitiko chekutengesa muchina

Model:KGH30L

Supercharge kugadzirwa kwako kugadzirwa neKGH Jerry inogona kuroora kana kuroora Yakachengetedzwa ruoko chimiro chekunyudza chishandiso chekupa mari yekunyomba

Vhoriyamu: 30lKurera: 22.5t

Send Inquiry

Product Description Specification Application

Supercharge yako yekugadzira yekugadzira neKGH30L, iyo yekupedzisira 30L Jerry inogona kuroora kana kuroora Station Extrusing Block muchina unoisa chiyero chitsva che20l zvidhori zvekushandisa. Inoratidzira Chimiro Chakanyorwa-Chimiro Chishandiso Chishandiso, izvi muchina unovimbisa zvakanyanya kunyange simba rekunamatira, kuendesa mhinduro dzisina mhosva dzese nguva. Zvakanyatsokodzera inosanganisa zvakanyanya kugona kweiyo yepamusoro-tier mhando yekukubatsira iwe kutonga iyo musika. Yakagadzirirwa kunyatsoita uye kusimba, muchina uyu ndiwo wakakodzera mhinduro yemabhizinesi ari kutsvaga kusimudzira kugona kwavo uye gadzira premium pairating zvigadzirwa.

Zvimiro uye Zvakanakira

Gadziridza kugadzirwa kwako neyedu-station-station inoramba ichivhuvhuta muchina, yakagadzirirwa midziyo kusvika pamakumi matatu. Nekuchinja-chinja. "
Yakanakira mashandisirwo akafanana neshampoo, yekuwachira detergent, uye cosmetic kurongedza, muchina uyu unounza kugadzirwa kwakanyanya-kumhanya uchiramba uchichengetedza mhando yepamusoro-tier. Yayo inoshamisa uye inoshanda dhizaini inobatsira kuderedza kutambisa uye kuwedzera kubuda, ichiita kuti isimbe-inoshanda mhinduro inowedzera kudzoka kwako pakudyara kwako.

Specifications

serial number	Material PE、PP、PVC、PA...	High speed movement mode(curved arm)
serial number	Material PE、PP、PVC、PA...	Machine model:KGH30L
Specifications
1	Max container capacity	30 L
2	Output(dry Cycle)	450 PC/HR
3	Machine Dimension(L×W×H)	4.8 M x 2.1 M x 3.5 M
4	Machine weight	22.5T
Clamping Unit
1	Clamping force	300 KN
2	Mold platen size(W×H)	630 MM x 680 MM
3	Platen openingstroke	450 MM -1000 MM
4	Platen moving stroke	750MM
5	Max mold size(W×H)	730 MM - 680 MM
6	Mold thickness	480 MM - 580 MM
Power
1	Servooil pump motor power	22 KW
2	Servo pump displacement	200 L/MIN
3	Blowpressure	0.6 Mpa
4	Air consumption	1.8 M³/MIN
5	Cooling water pressure	0.2 Mpa - 0.3 Mpa
6	Water consumption	180 L/min
7	Average energy consumption	70 KW -80 KW
Extruder unit
1	Screw diameter	90 MM
2	Screw L/D ratio	25 L/D
3	Melting capacit for HDPE	180 Kg/hr
4	Number of heating zone	4 ZONE
5	Screw heating power	16 KW
6	Screw fanpower	0.9 KW
7	Extruder motor power	75 KW
Die head
1	Number of heating sections	3 * 8 ZONE
2	Heating power	6.5 KW
3	Maxdie-pin diameter	220 MM
4	Accumulator capacity	280 MM
5	(PE)Accumulator weight	170 MM
