183 Plastiki tafura yekugadzira muchina

Model:KGS120Z

Kinggle Kgs120z ndeyekucheka-gomba Zvakazara tata tafura yepurasitiki kana purasitiki yekuwedzera kuputika kuumbwa kwemuchina zvinodiwa

Vhoriyamu: 1000lKurera: 38T

Send Inquiry

Product Description Specification Application

Kgs120z 183 Plastiki tafura yekugadzira muchina inogadzira yepurasitiki panel mhando chigadzirwa, zvakadaro Senge tafura / Ware House etc. Yakasarudzika Platen Blow Buling Muchina unokwanisa kukwana Sangana neiyo yakakosha saizi yechigadzirwa zvigadzirwa zvinodiwa zvinodiwa, neakakwira-kumhanya kugadzirwa kuchengetedza iyo unit mutengo.
Inosanganisira moog 100 gobvu controller, robhoti ruoko, uye pasi kuputika system, kuisimudzira kubereka uye mhando.

Zvimiro uye Zvakanakira

Inoshandiswa kugadzira zvigadzirwa muindasitiri akasiyana siyana. Kunyangwe iri hombe yekugona kwekushambadzira-inodzivirira mumidziyo yemakemikari, kurongedza mabhodhi ane hutsinye mune zvechikafu zviyero zvezvigadzirwa zvezuva nezuva, zvinogona kuve zvakanyatso kudzorwa kuti usangane nemusika misika inoda.
Maitiro ekudyisa anotora kucheka-mashandiro emucheto uye anogadziriswa zvichibva pane yakakwirira-huwandu hwekugadzira maitiro e120z blow mold muchina. Rondedzera chaizvo kuyerera uye kugoverwa kwezvinhu zvisina kujairika kuti uve nechokwadi cheyureti yeiyo Ultra huwandu hwechigadzirwa, uye bvisa hurema hwakakonzerwa nekudyira zvisina kujairika.

Specifications

serial number	Material HDPE…	Mold closing oil cylinder(single cylinder)
serial number	Material HDPE…	Machine model:KGS120Z
Specifications
1	Max container capacity	1000 L
2	Output(dry Cycle)	300 PC/HR
3	Machine Dimension(L×W×H)	8.3 M ×3.4 M × 6.8 M
4	Machine weight	38 T
Clamping Unit
1	Clamping force	1200 KN
2	Mold platen size(W×H)	1300 MM×1900 MM
3	Platen openingstroke	600 MM-1600 MM
4	Platen moving stroke	700 MM
5	Max mold size(W×H)	1000 MM×2000 MM
6	Mold thickness	630 MM - 830 MM
Power
1	Servooil pump motor power	25 KW
2	Servo pump displacement	200 L/MIN
3	Blowpressure	0.8 Mpa
4	Air consumption	2 M²/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	120 L/min
7	Average energy consumption	110 KW -130 KW
Extruder unit
1	Screw diameter	120 MM
2	Screw L/D ratio	30 L/D
3	Melting capacit for HDPE	350 Kg/hr
4	Number of heating zone	6 ZONE
5	Screw heating power	32.5 KW
6	Screw fanpower	0.6 KW
7	Extruder motor power	90 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	38.8 KW
3	Maxdie-pin diameter	700(800) MM
4	Accumulator capacity	25(30) L
5	(PE)Accumulator weight	18(22) KG
