10l kuunganidza blow monline muchina

Model:KGB70A

KGB70a ndeyevessifile 10l inowedzera blow blow scusing muchina yakagadzirirwa max 15-litita bhodhoro rinoputika kuumbwa. Sechiratidziro chinotungamira chemvura bottle mugadziri, tinopa mhinduro dzakarongeka kuti tisangane nezvinodiwa nevatengi. Muchina hausi chete pamabhodhoro emvura chete, midziyo yekuuraya zvipembenene, uye zuva nezuva makemikari kurongedza kugadzirwa, asi zvakare kune zvidiki asi zvakaringana zvigadzirwa zvigadzirwa. Muchina uyu unosangana nezvinodiwa zvakasiyana siyana.

Vhoriyamu: 20lKurera: 7.8t

Send Inquiry

Product Description Specification Application

KGB70a 10l inowedzera blow buling Melding Machine ndeyekuvhura yakatarwa uye kuvhara Model, iyo inogamuchira zvakapetwa kaviri kudhonza tsvimbo synchronous kurira mechanism, mafuta Cylinder zvakananga kumanikidza kuvhara Mold, kuAccumulator Cylinder kufaira serise. Hydralic service system kudzora, nekukurumidza kupindura kumhanya uye kuchengetedza simba.
More suite kune idzo dzakakosha dhizaini shuwa chigadzirwa kugadzirwa, kunogona dzora chimiro uye kukora zvimwe chokwadi.

Zvimiro uye Zvakanakira

Iyi modhi ndeyekuvhura yakatarwa uye kushandisa molidhi yekuvhara, ichishandisa kaviri tsvimbo syncnoronous yemafirimu ekuvhara mechanism, uye iyo silinda cylinder zvakananga kudzvanywa kukwira mold
● Kuchengetedza silinda kufa musoro
● Maximum vhoriyamu 20l
● Zvakakodzera mabhodhoro emvura, midziyo yekuuraya zvipembenene, uye zuva nezuva makemikari kurongedza, nezvimwe.
● Iyo inosarudzika ndeyekuti inodzorwa neiyo hydraulic serdo system kuti uwane nekukurumidza mhinduro yekuita uye yakakwirira simba kugona.

Specifications

serial number	Material PE、PP、ABS ...	Mold closing oil cylinder(single cylinder)
serial number	Material PE、PP、ABS ...	Machine model:KGB70A
Specifications
1	Max container capacity	20L
2	Output(dry Cycle)	700 PC/HR
3	Machine Dimension(L×W×H)	4.3 M x1.7 M x3.9 M
4	Machine weight	7.8 T
Clamping Unit
1	Clamping force	130 KN
2	Mold platen size(W×H)	680 MM x 600 MM
3	Platen openingstroke	300 MM - 850 MM
4	Platen moving stroke	370 MM
5	Max mold size(W×H)	460 MM×600 MM
6	Mold thickness	310 MM - 380 MM
Power
1	Servooil pump motor power	11KW
2	Servo pump displacement	80 L/MIN
3	Blowpressure	0.8 Mpa
4	Air consumption	0.7 M²/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	60 L/min
7	Average energy consumption	18 KW-22 KW
Extruder unit
1	Screw diameter	70 MM
2	Screw L/D ratio	24 L/D
3	Melting capacit for HDPE	80 Kg/hr
4	Number of heating zone	3 ZONE
5	Screw heating power	12.6 KW
6	Screw fanpower	0.5 KW
7	Extruder motor power	22 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	20 KW
3	Maxdie-pin diameter	180 MM
4	Accumulator capacity	3 L
5	(PE)Accumulator weight	2.25 KG
