Iyo HMI ndiyo maonero emushandisi pamaitiro, kwete maitiro acho. Verengai tsika, mhinduro chaiyo, mamiriro emuchina, uye nhoroondo yealarm pamwe chete usati wachinja recipe.
Izvo zvakakosha zveHMI skrini zvakagadzirirwa kuratidza
Mazita escreen uye marongero anosiyana nemuchina, chirongwa chePLC, sarudzo, uye vhezheni yekutonga. Iwo epasi mabasa akafanana: sarudza modhi, raira chiito, isa chinangwa, ratidza mhinduro, ratidza kutevedzana mamiriro, uye taurira mushandisi kuti nei chiitiko chinotevera chakavharwa.
| Screen group | Ruzivo rwemhando | Mubvunzo wevashandi |
|---|---|---|
| Main / chimiro | Mode, cycle state, maalarm anoshanda, zvinzvimbo zvikuru uye chimiro chekugadzira | Mushini wacho uri kuitei manje? |
| Manual operation | Mold, blow pini, core dhonza, ngoro, robhoti, extrusion uye yekubatsira mirairo | Iyi nzira inogona kufamba zvakachengeteka uye inopindura here? |
| Tembiricha | Seta kukosha, kukosha chaiko, chimiro cheheater, kutsauka kwepamusoro / kuderera | Iyo melt system yakagadzikana uye yakagadzirira here? |
| Zvirongwa zvenguva | Kunonoka, nguva yekuridza, nguva yekutonhora, nguva yekufamba uye kutevedzana mahwindo | Nhanho yacho iri kutanga nekugumira payakarongwa here? |
| Kumanikidza uye kumhanya | Yakarairwa kumanikidzwa kana kumhanya kweakasarudzwa hydraulic mafambiro | Ko resipi yekufamba inokodzera iyi mold uye nhanho? |
| Kusarudzwa kwebasa | Yakaiswa kana yakagoneswa sarudzo uye otomatiki kutevedzana sarudzo | Chirongwa chakamirira sarudzo isiri kushandiswa? |
| Kupinza / kubuda | Sensor uye switch inoti; PLC inobuda mirairo | Mutongi anoona mamiriro anodiwa uye anopa murairo here? |
| Nhoroondo yealarm | Anoshanda uye apfuura maaramu ane nguva kana kurongeka | Imhosva ipi yakatanga kuitika? |
| Position / calibration | Platen kana accumulator chinzvimbo, mareferensi kukosha uye calibration minda | Nzvimbo yakaratidzwa inoenderana nenzvimbo yemuviri here? |
| Wall-thickness control | Profile mapoinzi, die-gap command, faira mabasa uye kuteedzera | Iyo mbiri inoenderana nechechi uye chikamu here? |
Shandisa iyoparison programming guideyemadziro-kukobvu skrini. Ichi chinyorwa chinotarisa pakutevedzana kwemuchina wakakura.
Verenga kukosha kweseti uye kukosha chaiko sepeya
A set value chikumbiro. Kukosha chaiko imhinduro. Kana vasingabvumirani, kushandura chikumbiro kunogona kuvanza chiratidzo pasina kutsvaga chikanganiso.
Kunzvimbo yetembiricha, tanga watarisa kana kubuda kweheater kuri kurairwa. Kana iyo yakakosha iri pamusoro peiyo chaiyo kukosha asi iyo inobuda inoramba yakadzimwa, ongorora mapermissives, alarm state, inobuda logic, wiring, contactor kana solid-state relay sezviri kushanda. Kana kubuda kuripo asi tembiricha isingasimuke, tarisa heater yedunhu uye sensor nzvimbo. Kana tembiricha chaiyo ichipfuura, tarisa tuning, sensor kuonana, switching Hardware, kutonhora uye ichangoburwa resipi shanduko.
Iyoyo pfungwa inoshanda kune chinzvimbo. Mold-open command haisi humbowo hwekuti platen yakafamba. Enzanisa mamiriro ekuraira, sensor mhinduro, hydraulic pressure, interlocks uye chimiro chemuviri.
A nhanho-nhanho nomwe aramu kugadzirisa kutevedzana
- Ita kuti nzvimbo yacho ive yakachengeteka.Misa otomatiki kufamba kana mamiriro acho achigona kukuvadza midziyo kana kufumura munhu. Tevedzera nzira yakatenderwa nechirimwa.
- Rekodha alarm yekutanga.Mufananidzo kana kunyora pasi meseji, nguva, modhi, chigadzirwa, resipi, nhanho yekutenderera uye chero chiitiko chakapfuura. Gare gare maaramu anogona kuva mhedzisiro.
- Usaise patsva nekukurumidza.Reset inogona kudzima yakanakisa clue. Verenga nhoroondo yealarm uye ona kuti ndechipi chakatadza kutanga.
- Ziva mamiriro asipo.Sarudza kana iyo inoteedzana yakamirira tembiricha yakagadzirira, gadhi yakavharwa, mold chinzvimbo, accumulator chinzvimbo, mweya wemhepo, hydraulic pressure, zvinhu, robhoti imba, kana imwe inobvumira.
- Enzanisa HMI chimiro nemuchina.Kana iyo skrini ikati switch yemuganhu yakadzimwa, tarisa mudziyo, chinangwa, tambo uye kurongeka. Kana iyo skrini ichiti yakabatidzwa asi chimiro chemuviri chisingabvumirani, mira uye ongorora.
- Shandisa manual mode chete mukati mekuita.Jog imwe michina panguva, ine nzvimbo chaiyo yakajeka uye ese anodiwa ekuchengetedza anoshanda. Usashandise mirairo yemanyorero kukunda isina kugadziriswa interlock.
- Simbisa kugadzirisa.Bvisa chikonzero, gadzirisa kamwe chete, mhanyisa cheki inodzorwa, wobva watarisa akati wandei otomatiki matenderedzwa usati wadzosera muchina kune yakajairika kugadzira.
Maitiro ekupinza uye anobuda masikirini anopfupisa kukanganisa
Chidzitiro chekupinza chinoratidza izvo PLC inogashira kubva kumasensa, switch uye ekunze masisitimu. Chidzitiro chinobuda chinoratidza zvinorairwa nePLC. Pamwe chete, ivo vanobatsira kupatsanura dambudziko rekutevedzana kubva kune dambudziko remumunda-mudziyo.
| Observation | Zvarinotaura | Ongororo inotevera |
|---|---|---|
| Sensor yemuviri inoshanduka, kupinza hakuite | Sensor, alignment, supply, wiring kana yekupinza chiteshi dambudziko | Ongorora mudziyo uye dunhu uchishandisa dhizaini yemagetsi |
| Inodiwa inopinza iripo, inobuda haibatike | Imwe inobvumidza, modhi, timer, alarm kana kutevedzana mamiriro ari kuvharira murairo | Wongorora mamiriro ekutevedzana uye ese ane hukama mamiriro |
| Output inobatidza, actuator haifambi | Kuburitsa mudziyo, vharafu, dhiraivha, hydraulic/pneumatic supply kana mechanical restriction | Tarisa kuraira pamudziyo wemunda uye ongorora nzira yesimba |
| Movement inoitika, chinzvimbo hachimbotsigire | Limit switch, transducer, chinangwa, calibration kana dambudziko rekuisa mhinduro | Enzanisa chimiro chemuviri nehuwandu hwemhinduro |
| Alarm inodzokororwa panzvimbo imwechete yekutenderera | Inodzokororwa nguva, chinzvimbo kana maitiro ekuita | Trend kukosha kwakabatana uye ongorora iyo chaiyo yekutevedzana shanduko |
Kumanikidza-kuburitsa mabasa, kana aripo, ndeevashandi vakadzidziswa kugadzirisa. Kupa simba kuburitsa kunze kweyakajairwa kutevedzana kunogona kugadzira kusingatarisirwe kufamba kana kukundwa maitiro ekupinda.
Maonero efekitari: dzora resipi, kwete muchina chete
Mazhinji anodzokororwa e "chikanganiso chemuchina" anotanga sekuchinja kusina kunyorwa zvinyorwa. Chechipiri shanduko inogara nhaka tembiricha yakasiyana, kunonoka, kukurumidza, kudzvanywa kana chimiro asi haina rekodhi yekuti sei yachinja. Iyo alarm inova yekutanga kuoneka mhedzisiro.
Rekodhi yefekitari inoshanda inosanganisira chigadzirwa uye nhamba yekuumbwa, modhi yemuchina, giredhi rezvinyorwa, yakabvumidzwa rekodhi rekodhi, mushandisi, zuva, chikonzero chekuchinja, kukosha kwekare, kukosha kutsva, kuyerwa mhedzisiro uye kubvumidzwa. Dzivirira mabikirwo ehunyanzvi uye rega vashandisi vagadzirise chete minda inodiwa nebasa ravo.
Chengetedza mafaera akagadzikana mushure mekutumwa uye mushure mekuchinja kwakabvumidzwa maitiro. Kana kukosha kusina gwaro rakanyorwa, chengetedzo kana basa, zvisimbise nemagetsi uye magwaro ekugadzirisa usati wagadzirisa. Kinggle's currentmushure mekutengesa sevhisi pejiinotsanangurawo kudzidziswa uye kudzivirira-kuchengetedza rubatsiro; tsigiro yemuchina-chaiyo inofanirwa kushandisa serial nhamba uye chaiyo software shanduro.
Mibvunzo inowanzo bvunzwa
Nei muchina usingatangi muotomatiki modhi?
Iyo inoteedzana inogona kunge yakamirira chengetedzo, tembiricha, chinzvimbo, kudzvanywa, zvinhu, robhoti, kana modhi mamiriro. Verenga aramu yekutanga inoshanda uye tarisa izvo zvine chekuita nazvo pane kudzokorodza kudzvanya kutanga.
Ndinokwanisa kusetazve alarm ndoenderera mberi nekugadzira?
Chete mushure mekunge chikonzero chanzwisiswa, nzvimbo yacho yakachengeteka, uye mamiriro akakodzera akadzorerwa. Kudzokororwa kudzokororwa kunogona kuvanza kukanganisa kwepakati kana kukonzera kukuvara kwemidziyo.
Ndeupi musiyano uripo pakati pezvinopinza uye zvinobuda?
Kupinza chiratidzo icho PLC inogamuchira, senge yekumisikidza switch kana kumanikidza mamiriro. Inobuda murairo unotumirwa nePLC, sekusimbisa valve, heater kana drive control.
Sei tembiricha chaiyo yakasiyana netembiricha yakatarwa?
Iyo zoni inogona kunge ichiri kudziya, kutonhora, kukanganiswa nekuyerera kwezvinhu, kuganhurwa nekukanganisa, kana kukanganiswa ne sensor, heater, switching kana kugadzirisa dambudziko. Tarisa mamiriro ekubuda uye nzvimbo yemuviri usati wachinja kukosha kweseti.
Vese Kinggle HMI skrini vakafanana here?
Kwete. Zvidzitiro uye mabasa anowanikwa anosiyana nemhando yemuchina, sarudzo, chirongwa chePLC, madziro-kukobvu controller uye software revision.
